Mud Pump

Nov 16, 2022

Mud Pump


Drilling pump is also called mud pump which transport high pressure, high specific gravity, high sand concentration drilling fluid to bottom of hole. Drilling fluid is used to cool bit, wash out bottom of hole, break rock and bring out debris. Drilling pump not only is indispensable and one of the most important processing equipments, but also is one of the three working machines of drilling rig.

Main Features
Products have been verified by API Q1 Quality System, comply with API Spec 7K and all the parts can be traced back;
Strong self-suction ability. No need to use feed pump in normal case;

Reasonable structure. Operating steadily and reliably
Valve pot, crankshaft, herringbone gear and other important parts are manufactured by high quality alloy steel. Herringbone gears adopt grinding process, which make the precision of gears higher;
Parts have high standardization degree, strong interchangeability, and fewer types of spare parts;
Advanced inspecting methods: three-coordinates measuring machine etc.;
Good low temperature-resistant performance. It will be in normal use below 45 degree;
Good anti corrosion performance. Available to use in high salinity coastal and marine environment;
Application of drilling pump remote information system can monitor and control remotely the running state of equipments on site in real time and reflect the working state of drilling pump completely, and realize the intercommunication among the equipment, control center and personnel, so as to make technical personnel and management personnel in any place can get date of every monitoring point, and respond in a timely manner;

Parameter Table

Item F500 F800 F1000 F1300 F1600
Power Rating HP(kw) 500 (373) 800 (597) 1000 (746) 1300 (969) 1600 (1193)
Stroke Rating SPM 165 150 140 120 120
Stroke Length(in /mm) 7.5” /190.5 9”/228.6 10”/254 12”/305 12”/305
Gear Ratio 4.286 4.185 4.207 4.206 4.206
Inlet Dia. (in/mm) 8”/203 10”/254 12”/305 12”/305 12”/305
Outlet Dia. (in) 4”
Flange 5000psi
5-1/8”
Flange 5000psi
5-1/8”
Flange  5000psi
5-1/8”
Flange  5000psi
5-1/8”
Flange 5000psi
Valve API5# API6# API6# API7# API7#
Max. Liner (in/mm) 6-3/4”/170 6-3/4”/170 6-3/4”/170 7”/180 7”/180
Overall Dimension L*W*H(mm) 3658*2709*2231 3963*3025*2410 4267*3167*2580 4617*3260*2600 4615*3276 *2688
Approx. Weight (kg) 9770 14500 18790 24572 24791
Stroke
per
Minute
Liner size (mm) and Pressure Rating (Mpa/psi)
φ170 φ160 φ150 φ140 φ130 φ120 φ110 φ100
9.4 10.6 12.1 13.9 16.1 18.9 22.5 27.2
1365 1540 1750 2010 2335 2740 3260 3945
Displacement (L/S) (gpm)
165 35.67 31.6 27.77 24.19 20.86 17.77 14.93 12.34
565 501 440 383 330 281 236 195
150 32.43 28.73 25.25 21.99 18.96 16.16 13.58 11.22
514 455 400 348 300 256 215 178
140 30.27 26.81 23.56 20.53 17.7 15.08 12.67 10.47
480 425 373 325 280 239 201 166
130 28.11 24.9 21.88 19.06 16.44 14 11.77 9.73
445 394 347 302 260 222 186 154
120 25.94 22.98 20.2 17.6 15.17 12.93 10.86 8.98
411 364 320 279 240 205 172 142
110 23.78 21.07 18.52 16.13 13.91 11.85 9.96 8.23
377 334 293 255 220 188 158 130
Based on 100% volumetric efficiency and 90% mechanical efficiency
