Dimensions Of Steel Tubes — Heavy | |||||
Nominal size | Outside diameter mm | Thickness mm | Mass of black tube kg/m | ||
Min. | Max. | Plain or screwed ends | Screwed and socketed | ||
DN 8 | 13.3 | 13.9 | 2.9 | 0.765 | 0.769 |
DN 10 | 16.8 | 17.4 | 2.9 | 1.02 | 1.03 |
DN 15 | 21.1 | 21.7 | 3.2 | 1.44 | 1.45 |
DN 20 | 26.6 | 27.2 | 3.2 | 1.87 | 1.88 |
DN 25 | 33.4 | 34.2 | 4 | 2.94 | 2.96 |
DN 32 | 42.1 | 42.9 | 4 | 3.8 | 3.83 |
DN 40 | 48 | 48.8 | 4 | 4.38 | 4.42 |
DN 50 | 59.8 | 60.8 | 4.5 | 6.19 | 6.26 |
DN 65 | 75.4 | 76.6 | 4.5 | 7.93 | 8.05 |
DN 80 | 88.1 | 89.5 | 5 | 10.3 | 10.5 |
DN 100 | 113.3 | 114.9 | 5.4 | 14.5 | 14.8 |
DN 125 | 138.7 | 140.6 | 5.4 | 17.9 | 18.4 |
DN 150 | 164. 1 | 166. 1 | 5.4 | 21.3 | 21.9 |
NOTE: The dimensions and masses comply with ISO 65. |
Chemical Requirement OF AS 1074 PIPES
Chemical Composition | Max % |
---|---|
S (Sulfur) | 0.045% |
P(Phosphorus) | 0.045% |
CE(Carbon equivalent) | 0.40% |
Mechanical Requirement OF AS 1074 Carbon Steel Pipe
2.1 PROCESS OF MANUFACTURE. Tubes may be either welded or seamless.
2.2 MATERIAL. Steel pipe production should be made of steel with a sulfur content of no more than 0.045% and a phosphorus content of no more than 0.045%. The carbon equivalent, as determined by the subsequent formula, should remain below 0.4: The selected pipe shall be cut out and its length or shape shown according to the AS 1391 standard |
AS 1074 Carbon Steel Pipe Testing
Nondestructive Testing:
Ultrasonic testing, magnetic particle testing, X-ray testing.
Hydraulic Pressure Test:
The pressure value depends on the size and design requirements of the steel pipe.
Bending Test:
The steel pipe is usually tested at 90 degrees.
Final Inspection Before Delivery:
Check the diameter, wall thickness, batch number, packaging, etc.
